MS Split Cotter Pin

MS Split Cotter Pin
MS Split Cotter Pin
Product Code : SCP 15
Brand Name : precise
Product Description

As an eminent enterprise, we manufacture and supply an exclusive range of MS Split Cotter Pin. Manufactured with the utilization of premium quality mild steel at par with the latest market trends, this cotter pin assures high durability. Offered cotter pin is extensively used in varied applications as low-tech shear pins, especially in engineering Industry. Designed in strict adhering to set industry norms, this MS Split Cotter Pin features outstanding stress resistance attribute and is unbeatable in quality.

Features:

  • Durability

  • Rust proof

  • Excellent strength

  • Simple to fit


Normal length (L): the nominal length is the distance from underside of the eye to the extreme end of the short leg.
Nominal size: The nominal size is the diameter of the hole for the receiving the split pins.

Dimension

Nominal size

1

1.2

1.6

2

2.5

3.2

4

5

6.3

8

10

13

16

d

Max

0.9

1

1.4

1.8

2.3

2.9

3.7

4.6

5.9

7.5

9.5

12.4

15.4

Min

0.8

0.9

1.3

1.7

2.1

2.7

3.5

4.4

5.7

7.3

9.3

12.1

15.1

a

Max

1.6

2.5

2.5

2.5

2.5

3.2

4

4

4

4

6.3

6.3

6.3

Min

0.8

1.2

1.2

1.2

1.2

1.6

2

2

2

2

3.1

3.1

3.1

b

=

3

3

3.2

4

5

6.4

8

10

12.6

16

20

26

32

c

Max

1.8

2

2.8

3.6

4.6

5.8

7.4

9.2

11.8

15

19

24.8

30.8


Min

1.6

1.7

2.4

3.2

4

5.1

6.5

8

10.3

13.1

16.6

21.7

27

The Dimensions and permissible tolerances on the dimensions is the indicated.

Material: unless otherwise specified, split pins shall be manufactured from half round mild steel wires

Finish: split pins shall be supplied with bright self-color finish unless otherwise specified by the purchaser. The end of each leg shall be beveled and shall be free from burrs

Designation: A split pin shall be designated by the nominal size, nominal length, the number of this standard and material (for other than steel only.)

  • Example 1: A split of nominal seize 5, nominal length 50mm and made of steel shall be designated as : Split pin 5 X 50  IS : 549

  • Example 2: A split pin of nominal size 10, nominal length 80mm and made of brass shall be designated as: Split Pin 10 X 80 IS: 549 Brass.

Sampling: Sampling and acceptance criteria shall conform to IS : 6821-1973  Methods for sampling non threaded fasteners.


Test: The samples selected for test, when cold shall permit half the length of the both the legs being best back through 180 and closed flat upon themselves without showing any sign of fracture.
